nmealib¶

nmealib logo

Modern C++20 library for parsing NMEA 0183 sentences and NMEA 2000 CAN messages, with typed models, validation, and extensible message handling.

Why nmealib¶

Unified parsing for NMEA 0183 and NMEA 2000
Python and C++ libraries with consistent APIs
Typed message classes for safer integrations
Built-in validation (including NMEA 0183 checksum handling)
Extensible architecture for new sentence/PGN support
CLI tool for quick parsing and debugging
Unit-tested codebase

Quick Start¶

CLI¶

Download the latest release from GitHub Releases, then parse a sentence:

./nmealib-cli '$GPGGA,123519,4807.038,N,01131.000,E,1,08,0.9,545.4,M,46.9,M,,*47'

Parse from a file/pipe:

cat nmea_sentences.txt | ./nmealib-cli

C++ Library¶

Add the library to your CMake project (see Installation Guide), then include and use it:

#include <nmealib.h>

int main() {
    std::string sentence = "$GPGGA,123519,4807.038,N,01131.000,E,1,08,0.9,545.4,M,46.9,M,,*47";
    try {
        auto msg = nmealib::NMEA0183::GGA::parse(sentence);
        std::cout << "Parsed GGA message: " << msg.toString() << std::endl;
        std::cout << "Latitude: " << msg.getLatitude() << std::endl;
        // Access other fields as needed
    } catch (const nmealib::ParseException& e) {
        std::cerr << "Failed to parse sentence: " << e.what() << std::endl;
    }
    return 0;
}

See using-nmealib for a full example project demonstrating library usage.

Python Library (PyPI)¶

Install from PyPI:

python -m pip install nmealib

Quick usage example:

import nmealib

raw_0183 = "$GPRMC,123519,A,4807.038,N,01131.000,E,022.4,084.4,230394,003.1,W,A,V*6A\r\n"
raw_2000 = "09F11260:342C71FF7FFF7FFD"

try:
    msg_0183 = nmealib.nmea0183.Nmea0183Factory.create(raw_0183)
    print(type(msg_0183).__name__)  # RMC
    print(msg_0183.get_latitude(), msg_0183.get_longitude())

    msg_2000 = nmealib.nmea2000.Nmea2000Factory.create(raw_2000)
    print(type(msg_2000).__name__)  # PGN127250
except nmealib.NmeaException as exc:
    print(f"Parse error: {exc}")

Use in PlatformIO¶

The library is published on the PlatformIO registry:

https://registry.platformio.org/libraries/fliuzzi02/nmealib

Add the dependency in your platformio.ini:

lib_deps =
    fliuzzi02/nmealib

Or install it with the PlatformIO CLI:

pio pkg install --library "fliuzzi02/nmealib"

An embedded reference example is available in examples/platformio-esp32.

Documentation¶

Companion usage repository: using-nmealib

Project Structure¶

nmealib/
├── .github/                  # CI workflow files
├── app/                      # CLI entrypoint
├── docs/                     # Documentation
├── examples/                 # Usage examples (including PlatformIO)
├── include/
│   ├── nmealib.h             # Main umbrella header
│   └── nmealib/
│       ├── nmeaException.h   # Custom exception class
│       ├── message.h         # Base Message class and utilities
│       ├── nmea0183.h        # Base NMEA 0183 class and utilities
│       ├── nmea2000.h        # Base NMEA 2000 class and utilities
│       ├── detail/           # Internal shared parsing/error helpers
│       ├── nmea0183/         # NMEA 0183 message type headers
│       └── nmea2000/         # NMEA 2000 message type headers
├── scripts/                  # CI/dev utility scripts
├── src/                      # Library implementation and parsing logic
├── tests/                    # Unit tests
├── CMakeLists.txt            # Root CMake project configuration
├── CMakePresets.json         # Preset build/test configurations
├── README.md                 # This file
└── library.json              # PlatformIO package manifest

Supported Protocols¶

All messages/PGNs listed in the Protocol Support are currently implemented and supported.

Messages/PGNs not listed are currently considered not implemented.

License¶

Licensed under MIT. See LICENSE.

Support¶

Open an issue in this repository for bugs/feature requests.
For usage questions, include sample input data and expected output.
